PLHZ-1 Anti-Drain Valve Performance Tester

A set of PLHZ-1 Anti-Drain Valve Performance Tester.
Technical Data
Oil Pump Flow Rate: 5 L/min
Temperature Control Range: room temperature to +100 °C
Tank Capacity: 20 liters
Motor Power: 0.25 kW
Power Supply Voltage: 380 V / 50 Hz
Heating Power: 1 kW
Machine Weight: 300 kg
Overall Dimension (L × W ×H): 1300×715×1160 mm
Main Features
  • This function automatically controls the calibration oil level.
  • The working table and fuel tank of the test table are made of stainless steel, and the pipes are made of high quality copper pipes and pipe joints.
  • The test method met the criteria: JB / T6725-93, ISO4548.
Applications

To determine the ability of the check valve of the rotary oil filter to prevent the loss of oil from the inside of the filter.

Downloads

To protect the documents privacy, please contact us to get the download password: info@pmfiltersolution.com

PLHZ-1 Data Sheet
PLHZ-1 Operation Instruction
